MAN D2862 LE489 Medium Duty

Engine

• Model Name:
  D2862 LE489 Medium Duty
• Range:
  D2862
• Manufacturer:
  MAN

Engine description

• No' of Cylinders:
  12
• Cylinder displacement:
  2 Litres
• Alternator output:
  120 Amp
• Flywheel housing:
  SAE 1
• Cooling system:
  Water

Performance data

• Bore
  128mm .
• Stroke
  157mm .

Combustion parameters

• Fuel consumption:
  263 Litres
• Intake air temperature:
  45℃
• Barometric pressure:
  1,000 mbar
• Sea water temperature:
  45℃

Exhaust

• Exhaust emissions:
  IMO Tier III/EPA Tier 4 Final
• Optimization of exhaust emissions:
  IMO Tier III

Dimensions

• Height:
  1,272mm .
• Width:
  1,153mm .
• Length without gearbox:
  2,139mm .
• Total displacement:
  24 Litres
• Mass
  2,420kg

Other

• In production?
  Yes
