Caterpillar C18 C ACERT C01 - IMO Tier II
Key Specifications
-
RATED OUTPUT:715 bhp / 533 KW / 725 mhp
-
RATED SPEED:Max 2,100 rpm
-
DISPLACEMENT:18.1 Litres
-
CYLINDERS:6 In-line
-
BORE & STROKE145mm bore , 183mm stroke
-
EMISSION COMPLIANCE:EU Stage III A , IMO Tier II
C18 C ACERT C01 - IMO Tier II Full Specfications
Engine
-
Model Name:C18 C ACERT C01 - IMO Tier II
-
Range:C18
-
Manufacturer:Caterpillar
Engine description
-
No' of Cylinders:6
Performance data
-
Bore145mm .
-
Stroke183mm .
-
Rotation:CCW(Standard Rotation)
Exhaust
-
Exhaust emissions:IMO Tier II/EU Stage III A
Dimensions
-
Height:1,300mm .
-
Width:1,204mm .
-
Length without gearbox:1,931mm .
-
Total displacement:18 Litres
-
Mass1,950kg
Other
-
In production?Yes
-
Solas Compliance?No
