Caterpillar C32 ACERT E02 - U.S. EPA Tier 3 and IMO Tier II/III
Key Specifications
-
RATED OUTPUT:1,800 bhp / 1,342 KW / 1,825 mhp
-
RATED SPEED:Max 2,300 rpm
-
DISPLACEMENT:32.1 Litres
-
CYLINDERS:V12
-
BORE & STROKE145mm bore , 162mm stroke
-
EMISSION COMPLIANCE:EU Stage III A , EPA Tier 3 , IMO Tier II
C32 ACERT E02 - U.S. EPA Tier 3 and IMO Tier II/III Full Specfications
Engine
-
Model Name:C32 ACERT E02 - U.S. EPA Tier 3 and IMO Tier II/III
-
Range:C32
-
Manufacturer:Caterpillar
Engine description
-
No' of Cylinders:12
Performance data
-
Bore145mm .
-
Stroke162mm .
-
Rotation:CCW(Standard Rotation)
Exhaust
-
Exhaust emissions:IMO Tier II/EPA Tier 3/EU Stage III A
Dimensions
-
Height:1,445mm .
-
Width:1,482mm .
-
Length without gearbox:2,103mm .
-
Total displacement:32 Litres
-
Mass3,075kg
Other
-
In production?Yes
-
Solas Compliance?No
